Digit DP: Counting Constrained Integers in [L, R] via Tight/Leading-Zero State Automata

7 min read Module 6.3: Advanced DP State Spaces & Algebraic Optimizations Updated Oct 23, 2026
📄 Cheat Sheet
Introduction to Digit Dynamic Programming — Counting Constrained Numbers
Kartik Arora Introduction to Digit Dynamic Programming — Counting Constrained Numbers Watch on YouTube ↗

Explains the prefix reduction count(R) - count(L-1), the `tight` lexicographic flag, and the `started` leading-zero flag.

0:00 / --:--

1. Prefix Reduction $[L, R] \to [0, R] - [0, L-1]$ & The tight Automaton

To count integers $x \in [L, R]$ satisfying a digit predicate $P(x)$, we reduce the two-sided range query to two one-sided queries: $\text{solve}(R) - \text{solve}(L - 1)$ (or $\text{solve}(R) - \text{solve}(L) + P(L)$ when $L$ is a 1000-digit string). Let $S[0..n-1]$ be the base-10 digit string of the upper bound $R$ (most significant digit at index $0$).

Core Invariant — The tight (Prefix-Match) & started (Leading-Zero) Flags

When choosing digit $d$ at position $\text{pos} \in [0..n-1]$:
1. tight Flag (bool): tight == true iff every previous digit $0..\text{pos}-1$ was chosen equal to $S[0..\text{pos}-1]$.
- If tight == true, $d$ is restricted to $0 \le d \le S[\text{pos}]$, and next_tight = (d == S[pos]).
- If tight == false, our prefix is already strictly smaller than $S$'s prefix! Thus $d$ can be any digit $0 \le d \le 9$, and next_tight = false forever.
2. started Flag (bool): Shorter numbers (e.g., $42$ when $R = 5000$) are generated as $0042$. When the problem depends on leading zeros (such as "no adjacent equal digits", where $0042$ has two leading $0$s that are NOT real digits, or "count occurrences of digit $0$"), started == false indicates we are still in the leading-zero prefix, and next_started = started || (d > 0).

2. Cross-Query Memoization Trick: Caching tight == false Across Multiple Test Cases

Observe a powerful structural fact: whenever tight == false, the remaining transitions from (remaining_len, state) depend only on 0..9 and do NOT depend on the input number $R$ at all! Therefore, if you index your memo table by remaining_len = n - 1 - pos and memoize only states where tight == false (and started == true), you can allocate and populate the memo table ONCE globally and answer $Q = 10^5$ range queries $[L_q, R_q]$ without ever clearing memo!

flowchart LR Root["pos=0, tight=true
Bound R = '352'"] -->|"d = 3 (Matches R[0])"| T1["pos=1, tight=true
Allowed d in [0..5]"] Root -->|"d in {0, 1, 2} (< R[0])"| F1["pos=1, tight=false
Allowed d in [0..9] (Memoized!)"] T1 -->|"d = 5"| T2["pos=2, tight=true
Allowed d in [0..2]"] T1 -->|"d in [0..4]"| F2["pos=2, tight=false
Shares Memo with F1's children!"] F1 -->|"d in [0..9]"| F2

Hardware Reality — Flat Static Array memo[20][STATE] vs. Clearing on tight == true

For a 64-bit integer $R \le 10^{18}$ ($n \le 19$ digits), at each position pos there is at most one reachable prefix with tight == true (namely, the unique prefix equal to $S[0..\text{pos}-1]$). Thus tight == true states never overlap within a single call! Only tight == false states are reached via multiple paths and benefit from memoization.

3. Complexity Matrix

SOS DP (Sum Over Subsets) Hypercube, Digit DP & Broken Profile Tiling
O(N·2^N) SOS / Broken Profile

Trace dimension-by-dimension SOS DP bit-flips F[mask] += F[mask ^ (1<<i)] without overcounting, Broken Profile staircase wavefront domino tiling, and Digit DP tight-prefix automata.

Step 1 / 7
Custom Input:
Timeline

Invariant & State

SOS DP Invariant: After outer loop dimension i, F[mask] aggregates all submasks that may differ from mask only in bits 0..i (zero duplicate paths!).
🔗 Live Pointer & State Transition Graph — SOS DP (Sum Over Subsets) Hypercube, Digit DP & Broken Profile Tiling Active Pointer Jump/Transition Matched/Optimal
00₂ F[00]… [0] Dim i=0 F[01]… [1] 10₂ F[10]… [2] Dim i=1 F[11]… [3]
[0]F[00]=a₀00₂
[1]F[01]=a₀+a₁ (bit 0)Dim i=0 merged
[2]F[10]=a₂10₂
[3]F[11]=a₂+a₃ (bit 0) → +F[01] (bit 1)Dim i=1 → ∑ all 4
3^N Submask Loop
O(3^N) = 59,049 (N=10)
SOS DP N·2^N
O(N·2^N) = 10,240 (N=10)
Update Rule
if (mask & (1<<i)) F[mask] += F[mask^(1<<i)]
[Step 1] Swept dimensions i = 0..N-1; each hypercube edge is traversed once in O(N · 2^N).
Digit DP Problem Automaton State $\Sigma$ Digits $D = \log_{10} R$ Time Complexity Space Complexity
Digit Sum $\equiv 0 \pmod K$ $\text{rem} \in [0..K-1]$ O(log_10 R) O(10 * D * K) O(D * K)
No Adjacent Equal Digits $\text{last\_d} \in [0..10]$ O(log_10 R) O(10 * D * 11) O(D * 11)
Numbers with Distinct Digits $\text{mask} \in [0..2^{10}-1]$ O(log_10 R) O(10 * D * 1024) O(D * 1024)
Avoid Substring Pattern $P$ KMP Automaton $\text{state} \in [0..|P|]$ O(log_10 R) O(10 * D * |P|) O(D * |P|)

4. Reference C++20 Implementation

#include <cstring>
#include <string>
#include <vector>

// Count numbers in [0, R] with no two adjacent equal digits (demonstrates both tight and started)
long long count_no_adjacent_equal_digits(long long R) {
    if (R < 0) return 0;
    if (R == 0) return 1;
    std::string s = std::to_string(R);
    const int n = static_cast<int>(s.size());

    // memo[pos][last_digit][started] for tight == false states (last_digit = 10 means none yet)
    long long memo[20][11][2];
    std::memset(memo, -1, sizeof(memo));

    auto dfs = [&](auto& self, int pos, int last_d, bool tight, bool started) -> long long {
        if (pos == n) return 1LL; // Successfully formed a valid number (including 0 if !started)
        if (!tight && memo[pos][last_d][started] != -1) {
            return memo[pos][last_d][started];
        }

        int limit = tight ? (s[pos] - '0') : 9;
        long long ways = 0;

        for (int d = 0; d <= limit; ++d) {
            bool next_started = started || (d > 0);
            // Adjacent equality constraint only applies once the number has actually started!
            if (started && d == last_d) continue;

            int next_last = next_started ? d : 10;
            bool next_tight = tight && (d == limit);
            ways += self(self, pos + 1, next_last, next_tight, next_started);
        }

        if (!tight) {
            memo[pos][last_d][started] = ways;
        }
        return ways;
    };

    return dfs(dfs, 0, 10, true, false);
}

long long count_range_no_adjacent_equal(long long L, long long R) {
    return count_no_adjacent_equal_digits(R) - count_no_adjacent_equal_digits(L - 1);
}

Production Pitfall — Reusing tight == false Memo Across Different-Length Strings Indexed by pos

If you reuse a global memo table across multiple calls $\text{solve}(R)$ and $\text{solve}(L-1)$ where $R$ has $18$ digits and $L-1$ has $12$ digits, indexing memo by left-to-right pos is a fatal bug! pos = 3 in an 18-digit number has $15$ digits remaining, whereas pos = 3 in a 12-digit number has $9$ digits remaining! To share memo across numbers of different lengths, always index by rem_len = n - pos (number of digits remaining to be placed).

Check yourself Question 1 of 4
Concept Check Core Invariant Check recall

In Digit DP over a base-10 upper bound string $R$, why must the memoization table only cache states where `tight == false` (or store `tight` carefully if cleared per bound) when a single memo table is shared across `solve(R)` and `solve(L - 1)`?

⚡ Interactive Challenge · Staff Level

Algorithmic Design & Complexity Check

Analyze the invariant, asymptotic bound, and hardware behavior before selecting.

You want to count integers $x \in [1, R]$ ($R \le 10^{18}$) that are divisible by their own sum of digits ($x \bmod S(x) == 0$). Since $S(x)$ is only known at the end of the number, how do you design the Digit DP state?

Key Takeaways

Digit DP reduces range queries [L, R] to prefix queries solve(R) - solve(L - 1) over the base-10 (or base-2) digit representation of the upper bound.
The boolean tight flag tracks whether the prefix chosen so far equals the upper bound's prefix; once tight becomes false, all digits 0..9 are legal.
The boolean started flag distinguishes leading padding zeros (which are not real digits of a shorter integer) from internal zeros after the first non-zero digit.
Indexing the memo table by remaining length (n - pos) and caching only !tight states allows a single global memo table to be reused across all queries without resetting.
